Functional tests
- Leak test
- Burst pressure test
- Heat ageing
- Thermal shock test
- Temperature shock test
- Pressure pulsation test
- Vibration test
- Deflection test
- Permeation testc
- Lifetime simulation (pressure/temperature)
- Corrosion
Leak test
Helium detector
Flow meter
Air under water
UV-sensitive dye
Burst pressure test
Water/glycol
Air
Burst pressure test stand for liquid testing.
Temperature cycles
Hot/cold chambers
Heating stoves:
Temperature cycles
Hot/cold chamber accessible by car
Temperature shock
Movable chamber
Stationary chamber
Vibration test
One-dimensional oscillation
Vibration patterns:sine, random, shock
Shaker with hot/cold chamber
Shaking machine for tank tests in horizontal direction at room temperature
Drive simulation
Multidimensional movement
Shaking machine for tank tests in horizontal direction at room temperature
Drive simulation
Multidimensional movement
Checking the fuel line
Gasoline test (bi-thermal)
Fluid: gasoline, test fuels
Fluid pressure up to 50 bar Vibration (10-200Hz)
Diesel test (monothermal)
Testing the common rail line
High pressure test bench
Emission test
Measurement of permeation and emissions from fuel lines
Fluid pressure up to 3 bar
Test chamber with carrier gas control and HC analytics
Test cells mounted in the test chamber
CAC test
Bi-thermal test benches with deflection
- 5 test benches worldwide
- Up to 8 channels
Linear to multi-axis deflection, amplitude ±50mm Combination with vibration (10-200Hz) possible
Linear to multi-axis deflection, amplitude ±50mm Combination with vibration (10-200Hz) possible
4 test specimens mounted in the test stand
Testing hydraulic lines
Bi-thermal test bench
Fluid pressure up to 300 bar
Corrosion test
Salt spray chambers
